Excavator Compaction Wheels for 3 to 40 Tonne Machines
Excavator compaction wheels are padded steel drums that pin to the end of your excavator’s stick, in place of the bucket, so you can compact trench backfill, pads and batters with the machine already on site. AR Equipment makes seven sizes to suit excavators from 3 to 40 tonnes, with 80mm NM500 wear pads and a sealed axle built from an excavator track roller, priced from $2,200 ex-GST.
Every wheel is in stock at Burnside, QLD, and ships to your nearest depot Australia-wide. Pick your weight class and brand below, or call 1300 441 121 if you want us to confirm the fit first.
What an Excavator Compaction Wheel Is Used For
A compaction wheel does the job a plate compactor or trench roller would otherwise do, without a second machine or a bloke in the trench. The excavator operator rolls the wheel along the backfill in lifts, using the stick and boom to apply down-pressure, and the tapered pads knead the material rather than just pressing the surface.
On Australian civil and plumbing sites, the typical jobs are:
- Trench backfill over water, sewer, stormwater, gas and conduit runs, compacted in layers as the trench is filled
- Building pads and house slabs where fill needs to be consolidated before the base course goes down
- Batters and steep banks that a roller can’t safely drive on but an excavator can reach from the top or the toe
- Retaining wall backfill and narrow strips between structures where there’s no room for a ride-on
Done properly, you avoid the two things that cost money later: trench settlement that shows up as a dip across a driveway, and a failed compaction test that holds up the next trade. excavator trench buckets page covers the digging side of the same job.
Which Compaction Wheel Fits Your Excavator?
Size the wheel to the machine’s weight class first, then to the trench width. A wheel that’s too heavy for the excavator makes it tippy with the stick extended; too light and you’re not getting the down-force that compaction depends on.
- 5 to 6.5 tonne: 450mm overall, 400mm wheel, 280kg, $2,950 ex-GST
- 7 to 9 tonne: 450mm overall, 400mm wheel, 355kg, $3,500 ex-GST
- 11 to 14 tonne: 520mm overall, 450mm wheel, 461kg, $4,950 ex-GST
- 20 to 23 tonne: 650mm overall, 570mm wheel, 890kg, $8,250 ex-GST
- 24 to 29 tonne: 650mm overall, 570mm wheel, 925kg, $8,990 ex-GST
- 30 to 40 tonne: 750mm overall, 650mm wheel, 1,250kg, $10,990 ex-GST
The 400mm wheel is the workhorse for plumbers and small civil crews on 5 to 9 tonne machines, because it drops into a standard 450mm service trench with room to work. Running a 13-tonner on pipeline work? The 450mm wheel on the 11 to 14 tonne frame is the one. Wheels pin straight to your existing bucket pins or quick hitch, and we match the pin set to your brand when you order: Kubota, Cat, Hitachi, Komatsu, Kobelco, Sumitomo, Hyundai, Volvo, Sany, JCB, Yanmar or Bobcat.
Order now. Select your weight class and brand on the product page, or call 1300 441 121 to confirm the pin size.
How AR Equipment Compaction Wheels Are Built
Cheap compaction wheels fail in two places: the pads wear round, and the axle bearings pack with mud and seize. We’ve built around both.
80mm NM500 pads
The pads are 80mm high, cut from NM500 wear steel and welded to a rolled drum plate. NM500 is the abrasion-resistant grade used on crusher liners and bucket wear plates, so the pads hold their edge in sand, gravel and crushed rock backfill long after mild steel pads have gone round. The tapered pad profile pulls out of the fill cleanly instead of lifting it.
Sealed, maintenance-free axle
The axle is built from an excavator undercarriage track roller, which is already a sealed, oil-filled unit designed to run in mud all day under a 20-tonne machine. No grease nipples, no daily service, no bearings to repack. It’s the same part that lives under your tracks, doing the same job.
Mud scrapers between the pads
Scraper bars sit between the pad rows and clear sticky clay as the wheel turns, so the pads keep biting in wet conditions instead of turning into a smooth drum after ten metres.
Frame steel and pin bosses are sized for the weight class, with the heavier 20 to 40 tonne wheels rated for the down-pressure a large machine can put through the stick. Every wheel is covered by a 2 year warranty.
Watch the compaction wheel working trench backfill and pads:
The clips show the wheel working backfill in lifts and the pad impressions it leaves, which is a better guide to what it does than any spec table.
Why Buy Compaction Wheels From AR Equipment
- Designed and built for Australian fill. NM500 pads and sealed track-roller axles handle abrasive sands, wet clay and crushed rock.
- Seven sizes in stock, 3 to 40 tonne. Pin sets matched to your brand before dispatch.
- OEM supplier to Kubota, Cat, Hitachi, Bobcat, Volvo, JCB and ASV dealers. Same wheel, same price, direct.
- Parts and workshop at Burnside, QLD. Pads can be re-welded or replaced locally when they eventually wear.
- Finance up to $250,000 over four years, subject to approval. Repayment calculator on the product page.
Order now. Choose your excavator weight class and brand on the product page, or call 1300 441 121 and we’ll match the compaction wheel to your machine.
Frequently Asked Questions
What size compaction wheel do I need for a 5 tonne excavator?
The 5 to 6.5 tonne wheel, with a 400mm wheel face and 450mm overall width, weighing 280kg at $2,950 ex-GST. It drops into a standard 450mm service trench and is light enough that a 5-tonner stays stable with the stick extended. If you’re on the 7 to 9 tonne frame, the same wheel size comes in a heavier 355kg build.
Can a compaction wheel replace a plate compactor in a trench?
For backfill compaction in lifts, yes, and it keeps people out of the trench, which matters on anything over 1.5 metres deep. You still need to compact in layers of roughly 200 to 300mm rather than filling the trench and rolling the top. For final surface finish on a driveway base, a plate or roller still has a place.
Does the compaction wheel need greasing?
No. The axle is a sealed, oil-filled excavator track roller, so there are no grease points and no daily service. Check the pads for wear and keep the scrapers clear of packed clay, and that’s the maintenance list.
Will it fit my quick hitch?
Yes. The wheel is built with pin bosses matched to your excavator brand and weight class, so it fits your bucket pins directly or through your existing quick hitch. Select your brand when ordering. If you’re running a non-standard hitch or a tilt hitch, send us the pin diameter and centres and we’ll confirm.
How much do excavator compaction wheels cost in Australia?
AR Equipment compaction wheels run from $2,200 ex-GST for a 3 to 4 tonne machine up to $10,990 ex-GST for the 30 to 40 tonne size, with the popular 5 to 9 tonne wheels at $2,950 to $3,500. Freight to your nearest depot is quoted on top based on weight and destination.
Can I use a compaction wheel on steep banks?
Yes, that’s one of the main uses. The excavator reaches the batter from the top or toe and rolls the wheel down the face, compacting fill a ride-on roller couldn’t safely drive on. Keep the machine on stable ground, work within its reach and lift capacity, and compact in passes rather than trying to do the whole face in one go.
